Cell 600 (tube 1 7/8''-2'')

The 600 series are secure wrap-around hook clamps designed for use with 48 - 51 mm (1 7/8"– 2") tubes. Mounting hole suitable for up to 13mm (1/2"). Call or e-mail us today for more information or to request a quote.

Download PDF

Basic info

Description

The 600 series are secure wrap-around hook clamps designed for use with 48 - 51 mm (1 7/8"– 2") tubes. Mounting hole suitable for up to 13mm (1/2"). Call or e-mail us today for more information or to request a quote.

Key benefits

  • Hook clamp series designed to suit 48-51mm (1 7/8"-2") diameter tubes
  • M290 / M390 / M400 / M520 / M760 / 4 GS-35 / 4GS-50 / 4GS-62 compatible
  • Quick & easy attachment solution for moving heads & heavy fi xtures
  • Mounting hole suitable for up to 13mm (1/2") bolt
  • Precision extruded high tensile aluminium alloy
  • Polished surface with micropercussion marking
  • DGUV 17 / BGV C1 rating
  • Powder coated versions available on request
  • Supplied with M12 closing bolt & wingnut
  • Rated with SF 8:1 (kg) DGUV-17/BGV C1 (SWL1)
  • Rated with SF 4:1 (kg) 2006/42/EC (SWL2)
